Efficiency to 85%
UL 94V-0 Package Material
Internal SMD Construction
MTTF up to 2.9 Million Hours
Selection Guide
5V, 12V Input Types
Part Number
Nom. Input
Voltage
(VDC)
5
5
5
5
12
12
12
12
Rated Output
Voltage
(VDC)
5
9
12
15
5
9
12
15
Rated Output
Current
(mA)
400
222
167
133
400
222
167
133
Input Current
at Rated Load
(mA)
513
492
479
481
207
198
197
197
Efficiency
(%)
78
81
84
83
81
84
85
85
Isolation
Capacitance
(pF)
19
27
32
27
28
42
46
54
SIP4
Package
Style
R05I05
R05I09
R05I12
R05I15
R12I05
R12I09
R12I12
R12I15
Absolute Maximum Ratings
Input Voltage V
IN
Internal Power Dissipation
Lead Temperature
05V types
12V types
7VDC
15VDC
805mW
300擄C
Electrical Specifications
(measured at T
A
= 25擄C, at nominal input voltage and rated output current unless otherwise specified)
Input Voltage Range V
IN
(continuous operation)
Reflected Ripple Current (depending on the type)
Voltage Set Point Accuracy
Line Regulation (high V
IN
to low V
IN
)
Load regulation (depending on the type)
Ripple and Noise (BW=DC to 20MHz) (depending on the type)
Isolation Voltage (flash tested for 1 second)
Test Voltage (50Hz, 10 seconds)
Resistance (Viso = 500V)
Switching Frequency
Package Weight
Storage Temperature Range
Operating Temperature Range (all output types)
Case Temperature Above Ambient (depending on the type)
MTTF
1)
(depending on the type)
鈥?0擄C
+25擄C
+85擄C
SIP types
5V types
12V types
4.5VDC min. / 5.5VDC max.
10.8VDC min. / 13.2VDC max.
23 mA p-p min. to 38 mA p-p max.
see Tolerance Envelope
1.0% min. / 1.2% max. of V
IN
3.7% min. / 8.5% max.
45mVp-p min. / 200mVp-p max.
1000VDC min.
1000 Vpk min.
10 G鈩?min.
90kHz typ.
2.0 g
鈥?0擄C to +130擄C
鈥?0擄C min. to +85擄C max. (see graph)
+36擄C min. / +45擄C max.
417kHrs min. / 3970kHrs max.
328kHrs min. / 2327kHrs max.
222kHrs min. / 934kHrs max.
1).
Calculated using MIL-HDBK-217F with nominal input voltage at full load.
Please contact us, if you need exact parameters for the converter you have selected.
