ISL5740

TM

PRE LIM INARY

Data Sheet

June 2000

File Number

4821.2

3V Dual 10-Bit, 20/40/60MSPS A/D

Converter with Internal Voltage Reference

The ISL5740 is a monolithic, dual 10-bit analog-to-digital

converter fabricated in an advanced CMOS process. It is

designed for high speed applications where integration,

bandwidth and accuracy are essential. The ISL5740

features a 9-stage pipeline architecture. The fully pipelined

architecture and an innovative input stage enable the

ISL5740 to accept a variety of input con鏗乬urations, single-

ended or fully differential. Only one external clock is

necessary to drive both converters and an internal band-gap

voltage reference is provided. This allows the system

designer to realize an increased level of system integration

resulting in decreased cost and power dissipation.

The ISL5740 has excellent dynamic performance while

consuming less than 280mW power at 60MSPS. The A/D

only requires a single +3.0V power supply. Data output

latches are provided which present valid data to the output

bus with a latency of 5 clock cycles.

The ISL5740 is offered in 20MSPS, 40MSPS and 60MSPS

sampling rates.

Features

鈥?Sampling Rate . . . . . . . . . . . . . . . . . . . . . .20/40/60MSPS

鈥?9.1 Bits at f

IN

= 10MHz

鈥?Low Power at 60MSPS. . . . . . . . . . . . . . . . . . . . . .280mW

鈥?Power Down Mode . . . . . . . . . . . . . . . . . . . . . . . . . . 6mW

鈥?Wide Full Power Input Bandwidth. . . . . . . . . . . . . 400MHz

鈥?SFDR at f

IN

= 10MHz . . . . . . . . . . . . . . . . . . . . . . . . .70dB

鈥?Excellent Channel-to-Channel Isolation . . . . . . . . . . .75dB

鈥?On-Chip Sample and Hold Ampli鏗乪rs

鈥?Internal Bandgap Voltage Reference . . . . . . . . . . . . 1.25V

鈥?Single Supply Voltage Operation . . . . . . . . . .+2.7V - 3.6V

鈥?TTL/CMOS(3V) Digital Inputs CMOS Digital Outputs

鈥?Offset Binary or Two鈥檚 Complement Digital Data Output

Format

鈥?Dual 10-Bit A/D Converters on a Monolithic Chip

鈥?Pin Compatible Upgrade to AD9288

Pinout

鈥?Wireless Local Loop

鈥?PSK and QAM I&Q Demodulators

Ordering Information

PART

NUMBER

ISL5740/2IN

ISL5740/3IN

ISL5740/4IN

ISL5740/6IN

ISL5740 EVAL

TEMP.

RANGE

(

o

C)

PACKAGE

SAMPLIN

G RATE

PKG. NO. (MSPS)

Q48.7x7

Q48.7x7

Q48.7x7

Q48.7x7

20

30

40

60

鈥?Medical Imaging and Instrumentation

鈥?Wireless Communications Systems

鈥?Battery Powered Instruments

-40 to 85 48 Ld LQFP

-40 to 85 48 Ld LQFP

-40 to 85 48 Ld LQFP

-40 to 85 48 Ld LQFP

25

Pinout

AV

CC

I CLK

DV

CC

GND

ID9

ID7

ID6

ID8

ID4

ID3

ID5

ID2

Evaluation Platform

48 47 46 45 44 43 42 41 40 39 38 37

36

35

34

33

32

31

30

29

28

27

GND

I

IN

+

I

IN

-

DFS

IV

RIN

V

ROUT

QV

RIN

S1

S2

Q

IN

-

Q

IN

+

GND

1

2

3

4

5

6

7

8

9

10

ID1

ID0

GND

DV

CC

GND

AV

CC

AV

CC

GND

DV

CC

GND

QD0

QD1

26

11

25

12

13 14 15 16 17 18 19 20 21 22 23 24

DV

CC

GND

QD7

QD6

AV

CC

Q CLK

QD9

QD5

QD4

QD8

QD3

3-1

CAUTION: These devices are sensitive to electrostatic discharge; follow proper IC Handling Procedures.

1-888-INTERSIL or 321-724-7143

|

Intersil and Design is a trademark of Intersil Corporation.

|

Copyright

漏

Intersil Corporation 2000

QD2

next
