TS8388B Datasheet

  • TS8388B

  • ADC 8-BIT 1 GSPS

  • 340.00KB

  • 58頁

  • ATMEL   ATMEL

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

Features
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
8-bit Resolution
ADC Gain Adjust
1.5 GHz Full Power Input Bandwidth (-3 dB)
1 GSPS (min) Sampling Rate
SINAD = 44.3 dB (7.2 Effective Bits), SFDR = 58 dBc,
at F
S
= 1 GSPS, F
IN
= 20 MHz
SINAD = 42.9 dB (7.0 Effective Bits), SFDR = 52 dBc,
at F
S
= 1 GSPS, F
IN
= 500 MHz
SINAD = 40.3 dB (6.8 Effective Bits), SFDR = 50 dBc,
at F
S
= 1 GSPS, F
IN
= 1000 MHz (-3 dB FS)
2-tone IMD: -52 dBc (489 MHz, 490 MHz) at 1 GSPS
DNL = 0.3 lsb, INL = 0.7 lsb
Low Bit Error Rate (10
-13
) at 1 GSPS
Very Low Input Capacitance: 3 pF
500 mVpp Differential or Single-ended Analog Inputs
Differential or Single-ended 50鈩?ECL Compatible Clock Inputs
ECL or LVDS/HSTL Output Compatibility
Data Ready Output with Asynchronous Reset
Gray or Binary Selectable Output Data; NRZ Output Mode
Power Consumption: 3.4W at Tj = 70擄C Typical
Radiation Tolerance Oriented Design (150 Krad (Si) measured)
Two Package Versions
Evaluation board: TSEV8388B
Demultiplexer TS81102G0: Companion Device Available
ADC 8-bit
1 GSPS
TS8388B
Applications
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Digital Sampling Oscilloscopes
Satellite Receiver
Electronic Countermeasures/Electronic Warfare
Direct RF Down-conversion
Description
The TS8388B is a monolithic 8-bit analog-to-digital converter, designed for digitizing
wide bandwidth analog signals at very high sampling rates of up to 1 GSPS.
The TS8388B uses an innovative architecture,
including an on-chip Sample and Hold (S/H),
and is fabricated with an advanced
high speed bipolar process.
The on-chip S/H has a 1.5 GHz full power
input bandwidth, providing excellent dynamic
performance in undersampling applications
(High IF digitizing).
Rev. 2144C鈥揃DC鈥?4/03
1
