TPS62020, TPS62021
www.ti.com
SLVS076B 鈥?JUNE 2003 鈥?REVISED APRIL 2004
600 mA/1.25 MHz HIGH-EFFICIENCY STEP-DOWN CONVERTER
FEATURES
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Up to 95% Conversion Efficiency
Typical Quiescent Current: 18 碌A(chǔ)
Load Current: 600 mA
Operating Input Voltage Range: 2.5 V to 6.0 V
Switching Frequency: 1.25 MHz
Adjustable and Fixed Output Voltage
Power Save Mode Operation at Light load
Currents
Active-Low MODE pin on TPS62021
100% Duty Cycle for Lowest Dropout
Internal Softstart
Dynamic Output Voltage Positioning
Thermal Shutdown
Short-Circuit Protection
10 Pin MSOP PowerPad鈩?Package
10 Pin QFN 3 X 3 mm Package
DESCRIPTION
The TPS62020 is a high efficiency synchronous
step-down dc-dc converter optimized for battery pow-
ered portable applications. This device is ideal for
portable applications powered by a single Li-Ion
battery cell or by 3-cell NiMH/NiCd batteries. With an
output voltage range from 6.0 V down to 0.7 V, the
device supports low voltage DSPs and processors in
PDAs, pocket PCs, as well as notebooks and
subnotebook computers. The TPS62020 operates at
a fixed switching frequency of 1.25 MHz and enters
the power save mode operation at light load currents
to maintain high efficiency over the entire load current
range. For low noise applications, the device can be
forced into fixed frequency PWM mode by pulling the
MODE pin high. The difference between the
TPS62020 and the TPS62021 is the logic level of the
MODE pin. The TPS62021 has an active-low MODE
pin. The TPS62020 supports up to 600-mA load
current.
APPLICATIONS
PDA, Pocket PC and Smart Phones
USB Powered Modems
CPUs and DSPs
PC Cards and Notebooks
xDSL Applications
Standard 5-V to 3.3-V Conversion
Typical Application Circuit (600-mA Output Current)
EFFICIENCY
vs
LOAD CURRENT
V
I
2.5 V to 6 V
C3
10
碌F
TPS62020
2
VIN
3
VIN
1 EN
6
MODE
4
GND
SW
SW
FB 5
PGND 10
9
PGND
8
7
L1
10
碌H
V
O
0.7 V to V
I
/ 600 mA
C4
10
碌F
Efficiency 鈭?%
100
95
90
V
O
= 1.8 V
V
I
= 2.7 V
V
I
= 3.6 V
V
I
= 5 V
Mode = Low
R1
C1
85
80
75
70
65
60
55
50
45
40
0
R2
C2
V
I
= 3.6 V
Mode = High
0.01
0.10
1
10
100
1000
I
L
鈭?Load Current 鈭?mA
Please be aware that an important notice concerning availability, standard warranty, and use in critical applications of Texas
Instruments semiconductor products and disclaimers thereto appears at the end of this data sheet.
PowerPad is a trademark of Texas Instruments.
PRODUCTION DATA information is current as of publication date.
Products conform to specifications per the terms of the Texas
Instruments standard warranty. Production processing does not
necessarily include testing of all parameters.
Copyright 漏 2003鈥?004, Texas Instruments Incorporated
