Safety standards and approvals:
EN 60950 certified, rated for
250VAC (LVD test report)
UL-60950-1 / CSA C22.2 certified
6kVDC Isolation
UL94V-0 Package Material
Internal SMD Construction
Fully Encapsulated
Efficiency to 82%
ECONOLINE
DC/DC-Converter
RV
Series
Selection Guide
Part Number
DIP24 Miniature
RV-xx3.3S
RV-xx05S
RV-xx09S
RV-xx12S
RV-xx15S
RV-xx24S
RV-xx3.3D
RV-xx05D
RV-xx09D
RV-xx12D
RV-xx15D
Input
Voltage
(VDC)
3.3, 5, 9, 12, 15, 24
3.3, 5, 9, 12, 15, 24
3.3, 5, 9, 12, 15, 24
3.3, 5, 9, 12, 15, 24
3.3, 5, 9, 12, 15, 24
3.3, 5, 9, 12, 15, 24
3.3, 5, 12, 15, 24
3.3, 5, 12, 15, 24
3.3, 5, 12, 15, 24
3.3, 5, 12, 15, 24
3.3, 5, 12, 15, 24
Rated Output
Voltage
(VDC)
3.3
5
9
12
15
24
鹵3.3
鹵5
鹵9
鹵12
鹵15
鹵24
Output Current
Full Load
(mA)
600
400
222
167
133
83
鹵300
鹵200
鹵111
鹵83
鹵67
鹵42
2 Watt
DIP24 Miniature
Single
&
Dual Output
RV-xx24D
3.3, 5, 12, 15, 24
xx = Input Voltage Range
Description
The RV Series of DC/DC Converters are fully certified to EN 60950: 2000. This makes them ideal for all
Telecom and safety applications where approved isolation is required and UL-60950-1 / CSA C22.2.
Specifications
(Core Operating Area)
Input Voltage Range
Output Voltage Accuracy
Line Voltage Regulation
Load Voltage Regulation
(10% to 100% full load)
Output Ripple and Noise (20MHz limited)
Operating Frequency
Efficiency at Full Load
No Load Power Consumption
Isolation Voltage
Rated Working Voltage
Isolation Capacitance
Isolation Resistance
Short Circuit Protection
Operating Temperature Range (free air convection)
Storage Temperature Range
Relative Humidity
Package Weight
MTBF (+25擄C)
(+85擄C)
80
MSL Level 1
Detailed Information see
using MIL-HDBK 217F
Application Notes chapter "MTBF"
using MIL-HDBK 217F
鹵10%
鹵5%
1.2%/1% of Vin max.
3.3V output types
5V output type
9V, 12V, 15V, 24V output types
20% max.
15% max.
10% max.
200mVp-p max.
20kHz min. / 50kHz typ. / 85kHz max.
70% min. / 75% typ.
282mW min. / 338mW typ. / 400mW max.
(tested for 1 second)
(long term isolation)
6.000VDC min.
see Application Notes
Output Power (%)
100
80
60
40
20
0
-40
0
50
100
150
Derating-Graph
(Ambient Temperature)
2pF min. / 12pF max.
15 G鈩?min.
1 Second
-40擄C to +85擄C (see Graph)
-55擄C to +125擄C
95% RH
9g
1154 x 10
3
hours
168 x 10
3
hours
Safe Operating Area
85
Operating Temperature 擄C
}
