UL 94V-O Package Material
Internal SMD Construction
MTTF up to 1.6 Million Hours
BS EN 60950 Certified
Selection Guide
5V, 9, 12, 15V and 24V input types
Part
Number
RxxP1.8D
RxxP3.3D
RxxP05D
RxxP09D
RxxP12D
RxxP15D
Nom. Input
Voltage
(VDC)
5, 9,12, 15, 24
5, 9,12, 15, 24
5, 9,12, 15, 24
5, 9,12, 15, 24
5, 9,12, 15, 24
5, 9,12, 15, 24
Rated Output
Voltage
(VDC)
鹵1.8
鹵3.3
鹵5
鹵9
鹵12
鹵15
Rated Output
Current
(mA)
鹵278
鹵151
鹵100
鹵55
鹵41
鹵33
SIP7
Package
Style
Specifications
(measured at TA = 25擄C, at nominal input voltage and rated output current unless otherwise specified)
Input Voltage Range
Output Voltage Accuracy
Line Voltage Regulation
Load Voltage Regulation (10% load to rated load)
Ripple and Noise (20MHz BW)
Efficiency (at full load)
Isolation Voltage (flash tested for 1 minute)
Short Circuit Protection
Operating Temperature Range (all output types)
Storage Temperature Range
Please contact us, if you need exact parameters for the converter you have selected.
鹵10%
鹵5%
1.2% typ./1% of Vin
5V output types
other output types
15% max.
10% max.
200mVp-p max.
65% min.
5.2kVDC min.
1s
鈥?0擄C to +85擄C (see graph)
鈥?5擄C to +130擄C
EU 22
www.recom-international.com
