QTLP652C-B Datasheet

  • QTLP652C-B

  • SURFACE MOUNT LED LAMP STANDARD BRIGHT 1206 (Reverse Mount)

  • 405.80KB

  • 7頁

  • FAIRCHILD

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

SURFACE MOUNT LED LAMP
STANDARD BRIGHT 1206 (Reverse Mount)
QTLP652C-2
HER
QTLP652C-7
AlGaAs Red
PACKAGE DIMENSIONS
0.063 (1.6)
QTLP652C-3
Yellow
QTLP652C-B
Blue
QTLP652C-4
Green
0.063 (1.6)
TOP
5擄
0.043 (1.1)
0.126 (3.2)
0.012 (0.3)
SIDE
0.079 (2.0)
BOTTOM
POLARITY MARK
(See Note 2)
+
-
POLARITY
for -2, -3, -4 and -B
for -7
APPLICATIONS
鈥?Keypad backlighting
鈥?Push-button backlighting
鈥?LCD backlighting
NOTE:
1. Dimensions for all drawings are in inches (mm).
2. Cathode for -2, -3, -4 and B. Anode for -7.
DESCRIPTION
These surface mount chip LEDs are designed to 鏗乼 industry standard footprint. They are reverse mountable and designed to emit
light through a small cut-out hole in the PC board.
FEATURES
鈥?Small footprint - 3.2(L) X 1.6(W) X 1.1(H) mm
鈥?Wide viewing angle of 130擄
鈥?Water clear optics
鈥?Moisture-proof packaging
鈥?Available in 0.315" (8mm) width tape on 7" (178mm) diameter reel; 2,000 units per reel
漏 2003 Fairchild Semiconductor Corporation
Page 1 of 7
2/12/03
