鈥?/div>
50 W
atts
25 Watts at +25
擄
C Case Temperature
derated to zero at +150
擄
C
Copper Heat Sink Integral in the Molded Package
Resistance Range of 0.020 ohm to 10.0K
Resistor element is electrically isolated from
the mounting surface
50 Watts at +25
擄
C Case Temperature
derated to zero at +150
擄
C
Copper Heat Sink Integral in the Molded Package
Resistance Range of 0.20 ohm to 10.0K
Resistor element is electrically isolated from
the mounting surface
The MP825 and MP850 Kool-Pak
廬
Power Film Resistors are constructed with Caddock's
Micronox
廬
resistance film fired onto a flat ceramic substrate. The terminal attachment and resistance element geometry are configured to provide
outstanding non-inductive performance.
The ceramic substrate is bonded to a copper heat sink which becomes the metal mounting surface.
This assembly is molded in a high thermal conductivity molding compound with the copper heat sink flush with the back surface of the part.
Construction of MP825 and MP850:
MP808 and MP816 with an All Molded Package Configuration
8W
atts
MP 808 Kool-Pak
廬
Power Resistors
TO -126 Style Power Package
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
8 Watts at +25
擄
C Case Temperature
derated to zero at +150
擄
C
Thermally Conductive Molded Package
Lower Cost
Resistance Range of 0.020 ohm to 10.0K
Resistor element is electrically isolated from
the mounting surface
16 W
atts
MP 816 Kool-Pak
廬
Power Resistors
TO-220 Style Power Package
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
16 Watts at +25
擄
C Case Temperature
derated to zero at +150
擄
C
Thermally Conductive Molded Package
Lower Cost
Resistance Range of 0.10 ohm to 10.0K
Resistor element is electrically isolated from
the mounting surface
The MP808 and MP816 Kool-Pak
廬
Power Film Resistors are constructed with Caddock's
Micronox
廬
resistance film fired onto a flat ceramic substrate. The terminal attachment and resistance element geometry are configured to provide
outstanding non-inductive performance. The resistor body is completely surrounded by a high thermal conductivity molding compound to finish this
cost effective power resistor package.
Construction of MP808 and MP816:
RHOPOINT COMPONENTS LTD.
Holland Road
Hurst Green
Oxted, Surrey, RH8 9AX
漏 1999 Caddock Electronics, Inc.
CADDOCK
Tel: +44 (0)1883 717988
Fax: +44 (0)1883 712938
Email:
components@rhopoint.co.uk
Website:
www.rhopoint.co.uk/components/
IL-103.039
