MIC7122
Micrel
MIC7122
Rail-to-Rail Dual Op Amp
Preliminary Information
General Description
The MIC7122 is a dual high-performance CMOS operational
amplifier featuring rail-to-rail inputs and outputs.
The input common-mode range extends beyond the rails by
300mV, and the output voltage swings to within 150碌V of both
rails when driving a 100k鈩?load.
The amplifiers operate from 2.2V to 15V and are fully speci-
fied at 2.2V, 5V, and 15V. Gain bandwidth and slew rate are
750kHz and 0.7V/碌s, respectively at 2.2V supply.
The MIC7122 is available in the MM8鈩?8-lead MSOP pack-
age.
Features
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Small footprint MSOP-8 package
350碌A(chǔ) supply current per op amp at 2.2V supply
Guaranteed 2.2V, 5V, and 15V performance
750kHz gain-bandwidth product at 2.2V supply
0.01% total harmonic distortion at 1kHz (15V, 2k鈩?
Drives 200pF at 5V and greater supply voltages
Applications
鈥?Battery-powered instrumentation
鈥?PCMCIA, USB peripherals
鈥?Portable computers and PDAs
Ordering Information
Part Number
MIC7122BMM
Temperature Range
鈥?0擄C to +85擄C
Package
MSOP-8
Pin Configuration
OUT A 1
IN A鈥?/div>
2
8
7
6
5
V+
OUT B
INB鈥?/div>
INB+
1
2
A
3
B
4
8
7
6
5
IN A+ 3
V鈥?4
MSOP-8 (MM)
Pin Description
Pin Number
1/7
2/6
3/5
4
8
MM8 is a trademark of Micrel, Inc.
Micrel, Inc. 鈥?1849 Fortune Drive 鈥?San Jose, CA 95131 鈥?USA 鈥?tel + 1 (408) 944-0800 鈥?fax + 1 (408) 944-0970 鈥?http://www.micrel.com
Pin Name
OUTA / OUTB
INA鈥?/ INB鈥?/div>
INA+ / INB+
V鈥?/div>
V+
Pin Function
Amplifier Outputs
Inverting Inputs
Noninverting Inputs
Negative Supply: Negative supply for split supply application or ground for
single supply applications.
Positive Supply
March 1999
1
