4mm)
Shunts, position 2
MAX1572 EV kit PC board
C1, C2
2
C3
1
Ordering Information
PART
MAX1572EVKIT
TEMP RANGE
0擄C to +70擄C
IC PACKAGE
12 Thin QFN-EP*
C4
1
*EP
= Exposed paddle.
R1
JU1, JU2
L1
1
2
1
Recommended Equipment
鈥?Power supply capable of supplying 500mA from 2.6V
to 5.5V
鈥?Voltmeter
Quick Start
Follow the steps below to verify operation of the
MAX1572 EV kit.
Do not turn on the power supply
until all connections are completed:
1) Select the desired operating mode with JU1 and
JU2 (see Table 1).
2) Connect the positive terminal of the voltmeter to the
pad labeled OUT. Connect the ground terminal of
the voltmeter to the pad labeled GND nearest the
OUT pad. Connect a load from OUT to the GND
pad closest to OUT.
3) Preset the power supply to between 2.6V and 5.5V,
and turn the power supply off.
4) Connect the positive power-supply terminal to the
pad labeled IN. Connect the power-supply ground
to the pad labeled GND nearest the IN pad.
5) Turn on the power supply and verify the output volt-
age is 1.5V.
U1
None
None
1
2
1
Component Suppliers
SUPPLIER
Kamaya
Murata
Panasonic
Taiyo-Yuden
TDK
TOKO
PHONE
260-489-1533
770-436-1300
714-373-7939
408-573-4150
847-803-6100
847-297-0070
WEBSITE
www.kamaya.com
www.murata.com
www.panasonic.com
www.t-yuden.com
www.component.tdk.com
www.toko.com
Note:
When contacting these component suppliers, please
specify you are using the MAX1572
.
________________________________________________________________
Maxim Integrated Products
1
For pricing, delivery, and ordering information, please contact Maxim/Dallas Direct! at
1-888-629-4642, or visit Maxim鈥檚 website at www.maxim-ic.com.
