M14C64 Datasheet

  • M14C64

  • Memory Card IC 64/32 Kbit Serial IC Bus EEPROM

  • 129.34KB

  • 14頁

  • STMICROELECTRONICS   STMICROELECTRONICS

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

M14C64
M14C32
Memory Card IC
64/32 Kbit Serial I虜C Bus EEPROM
s
s
Compatible with I
2
C Extended Addressing
Two Wire I
2
C Serial Interface
Supports 400 kHz Protocol
Single Supply Voltage (2.5 V to 5.5 V)
Hardware Write Control
BYTE and PAGE WRITE (up to 32 Bytes)
BYTE, RANDOM and SEQUENTIAL READ
Modes
Self-Timed Programming Cycle
Automatic Address Incrementing
Enhanced ESD/Latch-Up Behaviour
1 Million Erase/Write Cycles (minimum)
40 Year Data Retention (minimum)
5 ms Programming Time (typical)
2
2
2
2
s
s
s
s
s
s
s
s
s
s
Micromodule (D20)
Micromodule (D22)
DESCRIPTION
Each device is an electrically erasable program-
mable memory (EEPROM) fabricated with STMi-
croelectronics鈥檚
High
Endurance,
Single
Polysilicon, CMOS technology. This guarantees
an endurance typically well above one million
Erase/Write cycles, with a data retention of
40 years. The memory operates with a power sup-
ply as low as 2.5 V.
The M14C32 is available in wafer form (either
sawn or unsawn) and in micromodule form (on
film). The M14C64 is available in micro-module
Wafer
Figure 1. Logic Diagram
VCC
Table 1. Signal Names
SDA
Serial Data/Address Input/
Output
Serial Clock
Write Control
Supply Voltage
Ground
SCL
WC
M14xxx
SDA
SCL
WC
V
CC
GND
GND
AI02217
October 1999
1/14
