IDT6116LA Datasheet

  • IDT6116LA

  • CMOS Static RAM

  • IDT

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

CMOS STATIC RAM
16K (2K x 8 BIT)
Integrated Device Technology, Inc.
IDT6116SA
IDT6116LA
FEATURES:
鈥?High-speed access and chip select times
鈥?Military: 20/25/35/45/55/70/90/120/150ns (max.)
鈥?Commercial: 15/20/25/35/45ns (max.)
鈥?Low-power consumption
鈥?Battery backup operation
鈥?2V data retention voltage (LA version only)
鈥?Produced with advanced CMOS high-performance
technology
鈥?CMOS process virtually eliminates alpha particle
soft-error rates
鈥?Input and output directly TTL-compatible
鈥?Static operation: no clocks or refresh required
鈥?Available in ceramic and plastic 24-pin DIP, 24-pin Thin
Dip and 24-pin SOIC and 24-pin SOJ
鈥?Military product compliant to MIL-STD-833, Class B
DESCRIPTION:
The IDT6116SA/LA is a 16,384-bit high-speed static RAM
organized as 2K x 8. It is fabricated using IDT's high-perfor-
mance, high-reliability CMOS technology.
Access times as fast as 15ns are available. The circuit also
offers a reduced power standby mode. When
CS
goes HIGH,
the circuit will automatically go to, and remain in, a standby
power mode, as long as
CS
remains HIGH. This capability
provides significant system level power and cooling savings.
The low-power (LA) version also offers a battery backup data
retention capability where the circuit typically consumes only
1碌W to 4碌W operating off a 2V battery.
All inputs and outputs of the IDT6116SA/LA are TTL-
compatible. Fully static asynchronous circuitry is used, requir-
ing no clocks or refreshing for operation.
The IDT6116SA/LA is packaged in 24-pin 600 and 300 mil
plastic or ceramic DIP and a 24-lead gull-wing SOIC, and a 24
-lead J-bend SOJ providing high board-level packing densi-
ties.
Military grade product is manufactured in compliance to the
latest version of MIL-STD-883, Class B, making it ideally
suited to military temperature applications demanding the
highest level of performance and reliability.
FUNCTIONAL BLOCK DIAGRAM
A
0
V
CC
ADDRESS
DECODER
A
10
128 X 128
MEMORY
ARRAY
GND
I/O
0
INPUT
DATA
CIRCUIT
I/O
7
I/O CONTROL
CS
OE
WE
CONTROL
CIRCUIT
3089 drw 01
The IDT logo is aregistered trademark of Integrated Device Technology, Inc.
MILITARY AND COMMERCIAL TEMPERATURE RANGES
漏1996
Integrated Device Technology, Inc.
For latest information contact IDT's web site at www.idt.com or fax-on-demand at 408-492-8391.
MARCH 1996
3089/1
5.1
1
