BZY97C10 GP........ BZY97C200 GP
1.5 W Zener Diodes
Dimensions in mm.
DO-41
(Plastic)
Voltage
10 to 200 V
Power
1.5 W
5
鹵 0.2
58.5
鹵0.5
Mounting instructions
1. Min. distance from body to soldering point,
4 mm.
2. Max. solder temperature, 350 擄C.
3. Max. soldering time, 3.5 sec.
4. Do not bend lead at a point closer than
2 mm. to the body.
鈥?/div>
Diffused junction
鈥?/div>
The plastic material carries
U/L recognition 94 V-0
鈥?/div>
Terminals: Axial Leads
鈥?/div>
Polarity: Color band denotes cathode
Maximum Ratings, according to IEC publication No. 134
P
tot
P
ZSM
T
j
T
stg
Power dissipation at Tamb = 60
o
C
Non repetitive peak zener dissipation
(t = 10 ms.)
Operating temperature range
Storage temperature range
1.5 W
40 W
鈥?55 to + 175 擄C
鈥?55 to + 175 擄C
Electrical Characteristics at Tamb = 25擄C
V
F
R
thj-a
Max. forward voltage drop at I
F
= 1.0 A
Max. thermal resistance at 10 mm.
lead length
1.1 V
50擄 C/W
Oct - 02
