ACST8 Datasheet

  • ACST8

  • OVER VOLTAGE PROTECTED AC POWER SWITCH

  • STMicroelectronics   STMicroelectronics

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

廬
ACST8
OVER VOLTAGE PROTECTED
AC POWER SWITCH
ASD鈩?/div>
(AC Switch Family)
MAIN APPLICATIONS
鈻?/div>
鈻?/div>
鈻?/div>
AC static switching in appliance & industrial
control systems
Washing machine with bi-rotational induction
motor drive
Induction motor drive for:
- refrigerator / freezer compressor
- air conditioning compressor
OUT
G
OUT
COM
G
OUT
COM
FEATURES
鈻?/div>
鈻?/div>
鈻?/div>
鈻?/div>
鈻?/div>
鈻?/div>
V
DRM
/V
RRM
= +/- 800V
Avalanche controlled device
I
T(RMS)
= 8A with T
CASE
= 90 擄C
High noise immunity: static dV/dt > 750 V/碌s
Gate triggering current : I
GT
< 30 mA
Snubberless turn off commutation:
(dI/dt)c > 4.5A/ms
TO-220FPAB
ACST8-8CFP
OUT
TO-220AB
ACST8-8CT
G
COM
BENEFITS
鈻?/div>
鈻?/div>
鈻?/div>
鈻?/div>
D
2
PAK
ACST8-8CG
Enables equipment to meet EN61000-4-5
standard
High off-state reliability with planar technology
Need no external overvoltage protection
Reduces the power component count
Table 1: Order Codes
Part Number
ACST8-8CFP
ACST8-8CT
Marking
ACST88C
DESCRIPTION
The ACST8-8C belongs to the AC power switch
family built around the ASD
TM
technology. This
high performance device is adapted to home appli-
ances or industrial systems and drives an induc-
tion motor up to 8A.
This ACST switch embeds a triac structure with a
high voltage clamping device to absorb the induc-
tive turn off energy and withstand line transients
such as those described in the IEC61000-4-5
standards.
ACST8-8CG
Figure 1: Functional Diagram
OUT
G
COM
TM:
ASD is a trademark of STMicroelectronics.
November 2004
REV. 6
1/10
