20 SCFM Coalescer
Type of contamination: oil
Physical Dimensions
Model #
3C-020-M02-P
Description
Metal Bowl, Manual Drain
Metal Bowl, Float Drain
Metal Bowl, Float Drain w/Indicator
Poly Bowl, Manual Drain
Poly Bowl, Float Drain
Poly Bowl, Float Drain w/Indicator
A
3.0
3.0
3.0
3.0
3.0
3.0
B
6.8
6.8
7.5
6.8
6.8
7.5
C
3.0
3.0
3.0
3.0
3.0
3.0
D
1.5
Coalescer
3C-020-M02-Fi
3C-020-P02-P
3C-020-P02-F
Front View
Side View
1.5
1.5
1.5
1.5
3C-020-P02-Fi
Specifications
Port Sizes
Thread Styles
Flow Capacity
Bowl Types
Maximum Temp.
& Pressure*
Filter Capacity
1/4"
NPT, BSPT, BSPP
20 SCFM
@ 100 PSI
Aluminum
Polycarbonate
Aluminum 175擄F, 200 PSIG
Polycarb. 125擄F, 150 PSIG
0.01 Micron and Larger
Order Guide
Port Size
Manual Drain
Float Drain
1/4"
1/4"
Metal Bowl
3C-020-M02-P
3C-020-M02-F
Metal Bowl
w/Indicator
3C-020-M02-Pi
3C-020-M02-Fi
Poly Bowl
3C-020-P02-P
3C-020-P02-F
Poly Bowl
w/Indicator
3C-020-P02-Pi
3C-020-P02-Fi
Replacement Parts & Accessories
Description
Bowl O-Ring
Metal Bowl Assembly,
Plastic Float Drain
Differential Indicator
Manual Drain
Brass Float Drain
Plastic Float Drain
Part Number
N32-95-009
N32-95-950
N32-W1-DPi
N32-95-182
N32-95-978
N32-95-973
Description
Replacement Element
Blanking Cap
Manual Flex Drain
Low Flow Plastic Drain
Poly Bowl,
Plastic Float Drain
Part Number
3C-020
N32-95-020
N32-95-610
N32-96-400
N32-15-160
Differential Pressure
< 1.5 PSID at Rated Flow
*For higher pressure applications, consult factory. If unit is equipped with
differential indicator, maximum temperature and pressure are 125擄F and
150 PSIG regardless of bowl design.
1-800-521-9200
7
Coalescer
3C-020-M02-F
1.5
1
2
3
4
5
6
