General Purpose Relays
SCHRACK
Miniature Power PCB RY II & RY II reflow-solderable
I
I
I
I
I
I
I
I
I
I
1 pole 8 A, 1 CO or 1 NO or 1 NC contact
Low component height 12.3 mm
5 kV / 8 mm coil-contact
Reinforced insulation (protection class II)
Pinnings: 3.2 and 5 mm
reflow-solderable version
Sockets with PCB-type terminals
Especially suitable for resistive and inductive loads on NO and NC contacts
Plastic materials according to IEC60335-1 (domestic appliances)
(not at reflow-solderable version)
F0142-F
RoHS compliant (Directive 2002/95/EC) as per product date code 0403
Applications: heating control, interface technology, domestic appliances, timers,
temperature control
Approvals
V
REG.-Nr.
of
5358,
Z
on request
E214025
Technical data approved types
Contact data
Contact configuration
Contact set
Type of interruption
Rated current
Rated voltage / max. switching voltage AC
Maximum breaking capacity AC
Contact material
Mechanical endurance
Rated frequency of operation with / without load
Contact ratings
Type
RY**1***
RY**1***
RY**(0,1,2)***
RY**(0,1,2)***
RY**(0,1,2)***
RY**(0,1,2)***
RY**(0)***
RY**(0,1,2)***
RY*** ***
RY**1 ***
1 CO or 1NO or 1NC
single contact
micro disconnection
8A
250/400 VAC
2000 VA
AgNi0,15, AgSnO
2
, AgCdO
30x10
6
cycles
6 / 1200 min
-1
Load
NO, 8 A, 250 VAC, resistive, 70擄C
NC, 8 A, 250 VAC, resistive, 70擄C
8 A, 30 VDC, UL 508
0,28 A, 250 VDC, UL 508
1/2 HP, 240 VDC, UL 508
1/4 HP, 120 VDC, UL 508
8 A, 415 VAC, resistive, UL 508
Pilot duty - B300, UL 508
CO, 8 A, 250 VAC, resistive, 70擄C
6(4)A, 250 VAC, 85擄C, EN60730
Cycles
1x10
5
5x10
4
3 x10
4
3 x10
4
6 x10
3
6000
5x10
3
1x10
5
Coil data
Rated coil voltage range DC coil
Coil power DC coil
Operative range
5...60 VDC
typ. 220 mW
2
Coil versions, DC-coil
Coil
Rated
Operate
Release
Coil
Rated coil
code
voltage
voltage
voltage
resistance
power
VDC
VDC
VDC
Ohm
mW
005
5
3,5
0,5
112+10%
223
006
6
4,2
0,6
162+10%
222
009
9
6,3
0,9
320+10%
253
012
12
8,4
1,2
627+10%
230
024
24
16,8
2,4
2350+10%
245
048
48
33,6
4,8
9391+10%
245
060
60
42,0
6,0
14000+10%
257
All figures are given for coil without preenergization, at ambient temperature +23擄C
Other coil voltages on request
1
Datasheet
Rev. HC1
Issued 2008/03
www.tycoelectronics.com
www.schrackrelays.com
Dimensions are in mm unless
otherwise specified and are
shown for reference purposes
only.
Product specification
according to IEC 61810-1.
Product data, technical para-
meters, test conditions and
processing information
only to be used together
with the 'Definitions' at
schrackrelays.com in the
鈥楽chrack鈥?section.
Specifications subject to
change.
