SURFACE MOUNT LED LAMP
1206 CHIP TYPE
-
Water Clear
PACKAGE DIMENSIONS
0.133 (3.4)
0.117 (3.0)
R0.016 (0.4)
HER
YELLOW
GREEN
AlGaAs RED
QTLP650C-2
QTLP650C-3
QTLP650C-4
QTLP650C-7
0.071 (1.8)
0.055 (1.4)
FEATURES
鈥?Ultra-miniature
TOP
CATHODE MARK
0.087 (2.2)
0.071 (1.8)
鈥?Extremely low profile
鈥?Industrial standard footprint
鈥?Wide viewing angle of 140擄
鈥?Water clear optics
0.051 (1.3)
0.035 (0.9)
鈥?Moisture-proof packaging
0.024 (0.6)
SIDE
0.020 (0.5)
DESCRIPTION
These surface mount lamps are designed to fit
industry standard profile and footprint for ultra-
miniature chip type 1206. The low profile and 140擄
viewing angle make this chip type LED ideal for
panel illumination, push-button backlighting and
membrane switch applications.
NOTE:
BOTTOM
Dimensions for all drawings are in inches (mm).
ABSOLUTE MAXIMUM RATINGS
Parameter
Continuous Forward Current - I
F
Peak Forward Current - I
F
(f = 1.0 KHz, Duty Factor = 1/10)
Reverse Voltage - V
R
(I
R
= 10 碌A(chǔ))
Power Dissipation - P
D
Operating Temperature - T
OPR
Storage Temperature - T
STG
Lead Soldering Time - T
SOL
Wave
Reflow
(T
A
= 25擄C unless otherwise specified)
Yellow
QTLP650C-3
20
160
5
85
-40 to +100
-40 to +100
260 for 5 sec
260 for 10 sec
Green
QTLP650C-4
30
160
5
100
AlGaAs Red
QTLP650C-7
30
160
5
100
Units
mA
mA
V
mW
擄C
擄C
擄C
HER
QTLP650C-2
30
160
5
100
1 of
5
3/14/00
300045A
