S
. R
le #E
L
Fi
U.
e
el
ct
ed
G
39
CO
716
E
Pa
a
ck
ge
s
Z
NI
ED
E2
TO-92
TO-202
*TO-220
3-lead
Compak
TO-263
D
2
Pak
TO-252
D-Pak
TO-251
V-Pak
*TO-3
Fastpak
MT2
MT1
G
Triacs
(0.8 A to 35 A)
E2
RoHS
General Description
These gated triacs from Teccor Electronics are part of a broad
line of bidirectional semiconductors. The devices range in current
ratings from 0.8 A to 35 A and in voltages from 200 V to 1000 V.
The triac may be gate triggered from a blocking to conduction
state for either polarity of applied voltage and is designed for AC
switching and phase control applications such as speed and tem-
perature modulation controls, lighting controls, and static switch-
ing relays. The triggering signal is normally applied between the
gate and MT1.
Isolated packages are offered with internal construction, having
the case or mounting tab electrically isolated from the semicon-
ductor chip. This feature facilitates the use of low-cost assembly
and convenient packaging techniques. Tape-and-reel capability
is available. See 鈥淧acking Options鈥?section of this catalog.
All Teccor triacs have glass-passivated junctions to ensure long-
term device reliability and parameter stability. Teccor's glass-
passivated junctions offer a rugged, reliable barrier against junc-
tion contamination.
Variations of devices covered in this data sheet are available for
custom design applications. Consult factory for more information.
漏2004 Littelfuse, Inc.
Thyristor Product Catalog
E2 - 1
Features
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
RoHS Compliant
Electrically-isolated packages
Glass-passivated junctions
Voltage capability 鈥?up to 1000 V
Surge capability 鈥?up to 200 A
Compak Package
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Surface mount package 鈥?0.8 A and 1 A series
New small profile three-leaded Compak package
Packaged in embossed carrier tape with 2,500
devices per reel
Can replace SOT-223
http://www.littelfuse.com
+1 972-580-7777
