BZX85C10RL Datasheet

  • BZX85C10RL

  • 1 Watt DO-41 Hermetically Sealed Glass Zener Voltage Regulat...

  • 8頁

  • ONSEMI

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

BZX85C3V3RL Series
1 Watt DO-41 Hermetically
Sealed Glass Zener Voltage
Regulators
This is a complete series of 1 Watt Zener diodes with limits and
excellent operating characteristics that reflect the superior capabilities
of silicon鈥搊xide passivated junctions. All this in an axial鈥搇ead
hermetically sealed glass package that offers protection in all common
environmental conditions.
Specification Features:
http://onsemi.com
Cathode
Anode
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Zener Voltage Range 鈥?3.3 V to 85 V
ESD Rating of Class 3 (>16 KV) per Human Body Model
DO鈥?1 (DO鈥?04AL) Package
Double Slug Type Construction
Metallurgical Bonded Construction
Oxide Passivated Die
Mechanical Characteristics:
CASE:
Double slug type, hermetically sealed glass
FINISH:
All external surfaces are corrosion resistant and leads are
AXIAL LEAD
CASE 59
GLASS
MARKING DIAGRAM
L
BZX
85C
xxx
YWW
readily solderable
MAXIMUM LEAD TEMPERATURE FOR SOLDERING PURPOSES:
230擄C, 1/16鈥?from the case for 10 seconds
POLARITY:
Cathode indicated by polarity band
MOUNTING POSITION:
Any
MAXIMUM RATINGS
Rating
Max. Steady State Power Dissipation
@ T
L
鈮?/div>
50擄C, Lead Length = 3/8鈥?/div>
Derate above 50擄C
Operating and Storage
Temperature Range
Symbol
P
D
Value
1
6.67
T
J
, T
stg
鈥?5 to
+200
Unit
W
mW/擄C
擄C
L
= Assembly Location
BZX85Cxxx = Device Code
=
(See Table Next Page)
Y
= Year
WW
= Work Week
ORDERING INFORMATION
Device
BZX85CxxxRL
BZX85CxxxRL2
Package
Axial Lead
Axial Lead
Shipping
6000/Tape & Reel
6000/Tape & Reel
* The 鈥?鈥?suffix refers to 26 mm tape spacing.
漏
Semiconductor Components Industries, LLC, 2002
1
February, 2002 鈥?Rev. 1
Publication Order Number:
BZX85C3V3RL/D
