Terminal Block Connectors
Vertical 101 Series
q
Standard profile 5mm pitch
q
Solid block construction
PRICE
INFORMATION
AND ORDERING
Horizontal 105 Series
q
Standard profile 5mm pitch
q
Modular interlocking construction
Vertical 200 Series
q
Standard profile 10mm pitch
q
Modular interlocking construction
Part number
Number of poles
**Insert required No. of poles
20.101/** SB
2-12 poles
Part number
Number of poles
**Insert required No. of poles
20.105/**
2-12 poles
Part number
Number of poles
**Insert required No. of poles
20.200/**
2-12 poles
Ratings
UL 1059
Rated voltage
Rated current
Wire size
Test voltage
Rated torque/screw size
300 V
15 A
CSA 22.2 No.158 EN 60998
300 V
15 A
250 V
24 A (T60)
2.5mm
2.0 kV
0.5 Nm/M3
2
UL 1059
Rated voltage
Rated current
Wire size
Test voltage
Rated torque/screw size
300 V
15 A
CSA 22.2 No.158 EN 60998
300 V
15 A
250 V
24 A (T60)
2.5mm
2.0 kV
0.5 Nm/M3
2
UL 1059
Rated voltage
Rated current
Wire size
Test voltage
Rated torque/screw size
300 V
15 A
CSA 22.2 No.158 EN 60998
300 V
15 A
750 V
24 A (T60)
2.5mm
2
3.0 kV
0.5 Nm/M3
AWG 22-14 AWG 22-14
AWG 22-14 AWG 22-14
AWG 22-14 AWG 22-14
Maximum rated cross section
Single wire (solid)
Stranded wire (flexible)
Stranded wire with Ferrules
2.5mm
2
1.5mm
2
1.5mm
2
Single wire (solid)
Stranded wire (flexible)
Stranded wire with Ferrules
2.5mm
2
1.5mm
2
1.5mm
2
Single wire (solid)
Stranded wire (flexible)
Stranded wire with Ferrules
2.5mm
2
1.5mm
2
1.5mm
2
Materials
Insulating material
Flammability class
Temperature range
Terminal block
Wire guard
Colour
Grey
PA
UL94 V-0
-30藲C/+105藲C
CuZn
stainless steel
RAL 7016
Insulating material
Flammability class
Temperature range
Terminal block
Wire guard
Colour
Grey
PA
UL94 V-0
-30藲C/+105藲C
CuZn
stainless steel
RAL 7016
Insulating material
Flammability class
Temperature range
Terminal block
Wire guard
Colour
Grey
PA
UL94 V-0
-30藲C/+105藲C
CuZn
stainless steel
RAL 7016
Dimensions
Spacing
PCB hole diameter
Stripped length
0.7
15
5.0mm
1.3mm
7.0mm
9
Spacing
PCB hole diameter
Stripped length
0.7
15
5.0mm
1.3mm
6.0mm
9
Spacing
PCB hole diameter
Stripped length
0.7
25
10.0mm
1.3mm
7.0mm
9
12.5
12.5
酶1
3.5
3.1
3.1
5
酶1
4
5
3.4
3.8
3.1
10
酶1
4
Options:
q
Modular interlocking construction
q
5.08mm PIN pitch version available
q
Printed terminals
Options:
q
5.08mm PIN pitch version available
q
Printed terminals
Options:
q
Printed terminals
